A web based cottage industry
offering high quality sport and scale rubber powered FF models

CB Model designs has now gone electric with the
JOULEBOX and APACHE II E-36 models

www.cbmodeldesigns.com




NEW RELEASE for 2021:

SUPER "J"
AMA Electric A/B Competition and Sport Model


The SUPER "J" is ready to ship!

Click on the thumbnail at the right to go to "Our Products" page, then further click on the "SUPER "J"" for the details of our newest kit

CB Model Designs is excited to enter into the AMA A/B arena. This model builds on the success of the JOULEBOX E-36.


NEW RELEASE for 2019:

eNostalgia Ramrod 280
class A size eNostalgia Competition and Sport Model


The eNostalgia RAMROD 280 is ready to ship!

Click on the thumbnail at the right to go to "Our Products" page, then further click on the "RAMROD 280" for the details of our newest kit

CB Model Designs is excited to be a part of the eNostalgia movement. This model, our rendition of the infamous 1/2 A Ramrod 250, is easy to build and fly, much like the original gas powered model.


News Flash for November 21, 2018:

We are now again shipping our P-30 kits with the Gizmo Geezer Adjustable Prop Assembly.

Thank you for your patience during the time when the Gizmo Geezer was unavailable. During this time we went with a comparable laser cut adjustable hub assembly of our own design which we called the Adjustable Thrust Bearing (ATB). The ATB filled the gap while the Gizmo Geezer was unavailable. Now that the Gizmo Geezer is available again, we decided to go back to it. Both front end assemblies are shown on the plans and instructions.

Our own Adjustable Thrust Bearing (ATB) kit, which was used for a short period of time when the Gizmo Geezer front ends were not available, is available separately by special order. Please contact us for pricing and availability of the ATB.


new in 2018:

Introducing the new improved

APACHE II MK II
E-36 Competition and Sport Model

The APACHE II has evolved into the APACHE II MK II.

The main design change is the MK II has a slightly longer nose moment to allow for a 7 x 6 folding prop.

The APACHE II MK II is the next generation of the APACHE design that has evolved from Ralph Ray’s 1960 Nationals winning 1/2A gas model which was kitted by Veco for many years.

Now completely re-envisioned into a state of the art E-36 / F1S electric free flight model, this design variant has undergone over a year’s worth of effort to design, flight test and refine it to this unique result.

This process has resulted in a model that is easy to build and flight trim while offering some of the highest performance found today in this class of model.

Intended for experienced free flight modelers, The APACHE II MK II is offered in short kit form to allow you to install the system of your choice for the drive train and electronics.

We also offer just the laser cut balsa and plywood parts by themselves if you want to build another model.

new in 2018:

Re-introduction of the JOULEBOX as the

JOULEBOX MK III
E-36 Competition and Sport Model

The venerable JOULEBOX just got even better!

The JOULEBOX 190 MK-II has been superseded by the JOULEBOX MK III.
In addition to the MKII upgrades of a redesigned fuselage with lower pylon, smaller fin and cleaner front end with an enclosed battery compartment, this version has been refined for additional weight reduction and installation provisions for the Cobra 2203/28 brushless E36/F1S motor

The JOULEBOX MK III is offered as a Short Kit, a Standard Kit and two Deluxe Kit options.

Deluxe Kit Option A comes with Starlink-Flitetech's electronic timer.
Deluxe Kit Option B comes with Texas Timers eMax electronic timer.

Both timers come with the optional RDT pigtail for use with your RDT system.

Both Deluxe Kit options come with all the other necessary drivetrain components (with the exception of the LiPo battery which the builder must supply). This includes a Cobra 2203/28 brushless motor, a set of 7.5 X 4 Graupner folding prop blades with a Texas Timers prop hub, a 12 Amp ESC, a micro servo for DT operation, an electrical connector set with 2MM bullet pin connectors for the ESC to motor connections and a Deans Micro single pin connector set for ESC to LiPo connection.


new last year in 2017

SUPER Y
P-30 and Small Mulvihill Model

The Super Y is our latest design to be released. It is a P-30 design with traditional lines. It succeeds our YARDSTICK and is more optimized for P-30 than the YARDSTICK was. Like our other models it a stick and tissue model that can be flown for sport or in competition.


2017 NATS News Flash
Lee Hines takes first in the FAI event F1S with his JOULEBOX 190 MK II
Drake Hooke wins AMA Electric "A" with his JOULEBOX 190 MK II with 8 maxes!


Click HERE for other NEWS FLASHES
where some of our other contest results are highlighted.


Click HERE for all of our fine kits.
